SPECIFICATIONS:
| Operating Modes | CW (continuous measurement); Color x/y (color temperature, x,y chromaticity coordinates, Y) Color u/v (color temperature, u,v chromaticity coordinates, Y), USB |
| Parameter Setting | 3 button operation; menu driven; setting with permanent storage in eeprom |
| Input Ranges | 4 channels, each with 6 ranges (-LS: 2.0.00 μA to 200.0 pA; -HS: 200.0 μA to 2.000 nA); automatic range switching |
| Display | LCD graphic display (97 x 32 pixel); 4 rows each 14 characters; LED background illumination with on/off switch |
| Measurement Method | Sampling A/D converter (xxx μs sample rate). Average reading processing time (integration) from 20 ms to 1 sec |
| Detector Head Connection | Detector heads with -5 type connector (9 pin MSDM9 socket, 4 signal inputs) |
| Manual Calibration | Input through USB interface; permanent storage in eeprom |
| Interface | USB Spec. 1.1 (HID device) |
| Operating Temperature | 5 to 40°C (41 to 104°F) - storage: 0 to 50°C |
| Power Supply | 2 x battery, size AA (2.2 to 3.2 V); current consumption: 6 mA + 30 mA for display illumination; USB powered in remote control mode |
| Dimensions/Weight | 145 x 63 x 30 mm / 150 g (5.7 x 2.5 x 1.2 in / 0.33 lb) |
DETECTOR LISTING:
| Radiometric Irradiance Detectors | ||||||||||
| reactor wavelength (nm) | detector model no. | spectral function (nm) | cosine diffuser dia. (mm) | typ. max. resolution | typ. max. value* | dim (mm) | ||||
| P-9710 | X1-1 HS | P-9710 | X1-1 HS | dia. | height | |||||
| 419 | BLU-009-5 | 400 to 470 | BLUE | 11 | 50 pW/cm2 | 500 pW/cm2 | 500 mW/cm2 | 50 mW/cm2 | 37 | 50 |
| 575 | VIS-3703-5 | 400 to 800 | VIS | 11 | 50 pW/cm2 | 500 pW/cm2 | 500 mW/cm2 | 50 mW/cm2 | 37 | 50 |
| 350 | UV-3701-5 | 315 to 400 | UV-A | 13 | 1.7 nW/cm2 | 17 nW/cm2 | 1.7 W/cm2 | 17 mW/cm2 | 37 | 32 |
| 300 | UV-3702-5 | 280 to 315 | UV-B | 11 | 25 nW/cm2 | 250 nW/cm2 | 10 W/cm2 | 1 W/cm2 | 37 | 50 |
| 253.7 | UV-3725-5 | 250 to 280 | UV-C | 11 | 5 nW/cm2 | 50 nW/cm2 | 2.5 W/cm2 | 250 mW/cm2 | 37 | 32 |
| *values calculated based on current measurement capability and may be limited by operating temperature, power density and other factors | ||||||||||
