ACCESSORIES:
- X1Z-01 USB interface cable (2 m) with terminal communication software and USB DLL
- BHO-04 Carrying case for X1 with one 37-type and one LDM-9901 detector
- BHO-05 Carrying case for X1 with RCH-0xx and RCH-1xx type detectors
- BHO-06 Carrying case for X1 with one 45-type detector
SPECIFICATIONS:
Operating Modes | CW (continuous measurement); Color x/y (color temperature, x,y chromaticity coordinates, Y) Color u/v (color temperature, u,v chromaticity coordinates, Y), USB |
Parameter Setting | 3 button operation; menu driven; setting with permanent storage in eeprom |
Input Ranges | 4 channels, each with 6 ranges (-LS: 2.0.00 μA to 200.0 pA; -HS: 200.0 μA to 2.000 nA); automatic range switching |
Display | LCD graphic display (97 x 32 pixel); 4 rows each 14 characters; LED background illumination with on/off switch |
Measurement Method | Sampling A/D converter (xxx μs sample rate). Average reading processing time (integration) from 20 ms to 1 sec |
Detector Head Connection | Detector heads with -4 type connector (9 pin MSDM9 socket, 4 signal inputs) |
Manual Calibration | Input through USB interface; permanent storage in eeprom |
Interface | USB Spec. 1.1 (HID device) |
Operating Temperature | 5 to 40°C (41 to 104°F) - storage: 0 to 50°C |
Power Supply | 2 x battery, size AA (2.2 to 3.2 V); current consumption: 6 mA + 30 mA for display illumination; USB powered in remote control mode |
Dimensions/Weight | 145 x 63 x 30 mm / 150 g (5.7 x 2.5 x 1.2 in / 0.33 lb) |
DETECTOR LISTING:
P-9710 (-2) & X1-1 (-4) Radiometric Irradiance Detectors | ||||||||||||
reactor wavelength (nm) | detector model no. | spectral function (nm) | cosine diffuser dia. (mm) | typ. max. resolution | typ. max. value* | dim (mm) | $ Price Connector Type | |||||
P-9710 | X1-1 HS | P-9710 | X1-1 HS | dia. | height | -2 | -4 | |||||
419 | SNERW-3706-2 SNERW-3706-4 |
400 to 470 | BLUE | 11 | 50 pW/cm2 | 500 pW/cm2 | 500 mW/cm2 | 50 mW/cm2 | 37 | 50 | 679 | 632 |
575 | SNERW-3703-2 SNERW-3703-4 |
400 to 800 | VIS | 11 | 50 pW/cm2 | 500 pW/cm2 | 500 mW/cm2 | 50 mW/cm2 | 37 | 50 | 978 | 930 |
350 | SNEUV-3701-2 SNEUV-3701-4 |
315 to 400 | UV-A | 13 | 1.7 nW/cm2 | 17 nW/cm2 | 1.7 W/cm2 | 17 mW/cm2 | 37 | 32 | 813 | 766 |
300 | SNEUV-3702-2 SNEUV-3702-4 |
280 to 315 | UV-B | 11 | 25 nW/cm2 | 250 nW/cm2 | 10 W/cm2 | 1 W/cm2 | 37 | 50 | 1030 | 983 |
253.7 | SNEUV-3718-2 SNEUV-3718-4 |
250 to 280 | UV-C | 11 | 5 nW/cm2 | 50 nW/cm2 | 2.5 W/cm2 | 250 mW/cm2 | 37 | 32 | 797 | 750 |
*values calculated based on current measurement capability and may be limited by operating temperature, power density and other factors |
